Λεπτομέρειες:
|
| Item | Specification Range | Description |
|---|---|---|
| Lifting Capacity | 1t – 100t (customizable) | Determined by girder configuration and crane design |
| Structure Type | Welded box structure / Plate structure | High-strength welding structure, compact design |
| Driving Type | Integrated motor with inverter (SEW/Nord/local) | Integrated gearbox, motor, and brake |
| Wheel Diameter | φ250 – φ500 mm | Material: 42CrMo or ZG340-640 |
| Wheel Base | 1.5m – 4.5m (customizable) | Designed according to span and working conditions |
| Traveling Speed | 2 – 45 m/min (VFD adjustable) | Smooth start and accurate positioning |
| Wheel Material | 42CrMo alloy steel, heat-treated and surface hardened | Wear-resistant, suitable for frequent operation |
| Installation Method | Bolt connection / Dowel pin alignment / Rail alignment | Precision-machined for easy girder mounting |
| Protection Level | IP54 – IP65 (depending on configuration) | Dust-proof and water-resistant for various environments |
| Working Temperature | -20°C ~ +50°C | Custom options available for extreme temperatures |
| Control Mode | Pendant control / Wireless remote / Cabin control | Flexible options to meet different site needs |
| Surface Treatment | Sandblasting + Epoxy primer + Polyurethane topcoat | Anti-corrosion for indoor and outdoor use |
